Major Tech 600V AC/DC TRMS Compact Smart Multimeter, CAT III 600V

Description

The MTD80 is a Compact True RMS Auto Ranging Multimeter with a 4000 count LCD backlit display. The meter always operates in the Smart mode “AUTO” function that automatically identifies DC voltage, AC voltage, Resistance and continuity buzzer and automatically displays the measurements.

Key points

• Brand: Veti
• Category: Test Instruments
• Model / SKU: MTD80

Specifications

• Function: Range
• DC Voltage: 0.001mV - 1000V
• AC Voltage: 0.001mV - 750V
• DC Current: 0.1mA-10A
• AC Current: 0.1mA-10A
• Duty Cycle: 1%-99%
• Resistance: 0.001Ω - 40.00MΩ
• Frequency: 99.99Hz - 9.999MHz
• Capacitance: 4.000nF-200.0µF
• Continuity: Yes
• Built-in buzzer: Yes
• Diode test: Yes

Ideal application

Electrical testing and troubleshooting by a qualified person.

Buying notes

Confirm voltage, mounting and any required accessories before purchase. Have a qualified electrician install fixed electrical equipment. Available from Superior Electrical in Potchefstroom - ask us if you need help choosing.
